Lennox G71MPP Unit Information

Page 41
TYPICAL AIR INTAKE PIPE CONNECTIONS
UPFLOW OR DOWNFLOW DIRECT VENT APPLICATIONS
(Right−Hand Exit in Upflow Application Shown)
FIGURE 21
PLUG
(Must be
glued in
place)
*Limit pipe length to 4" in
G71MPP−135 applications.
−36B−070
−36C−090
−60C−090
−36B−070
−36C−090
−60C−090
−60C−110
−36B−070
−36C−090
−60C−090
−60C−110
−60D−135*
2
2
2
2
2
2
2−1/2",
3" OR
4
TRANSITION
2"*
TRANSITION
2−1/2",
3" OR
4
FIGURE 22
TYPICAL AIR INTAKE PIPE CONNECTIONS
HORIZONTAL DIRECT VENT APPLICATIONS
(Horizontal Right−Hand Air Discharge Application Shown)
2”*
2”
2”
2”
TRANSITION
TRANSITION
2”
2−1/2”,
3” OR 4”
2−1/2”,
3” OR 4”
*Limit pipe
length to 4" in
−135 applications.
2”
−36B−070
−36C−090
−60C−090
−60C−110
−60D−135*
−36B−070
−36C−090
−60C−090
−60C−110
−36B−070
−36C−090
−60C−090
2”

Lennox G71MPP Specifications

General

Blower Motor	Variable-speed
Energy Star Certified	Yes
Warranty	Limited lifetime warranty on heat exchanger; 10-year limited warranty on covered components
Fuel Type	Natural gas
Ignition Type	Direct spark ignition
