Lennox HFC-410A Series Unit Information

Page 5
SPECIFICATIONS
General
Data
Model No. EL16XP1-042EL16XP1-048EL16XP1-060
Nominal Tonnage3.5
45
1
Sound Rating Number (dBA) 73 73 73
Connections
(sweat)
Liquid line (o.d.) - in.3/8 3/8 3/8
Suction line (o.d.) - in.7/8 7/
81
-1/8
Refrigerant
2
R-410A charge furnished 10 lbs. 12 oz.10 lbs. 7 oz.10 lbs. 4 oz.
Outdoor
Coil
Net face area - sq. ft. Outer coil 29.1 29.1 29.1
Inner coil 28.2 28.2 28.2
Tube diameter - in.5/165/1
65
/16
No. of rows 222
Fins per inch 22 22 22
Outdoor
Fan
Diameter - in.262
62
6
No. of blades 334
Motor hp 1/3 1/3 1/3
Cfm4150 4150 4250
Rpm820 82
08
20
Watts216 21
62
45
Shipping Data - lbs. 1 pkg. 294294 300
ELECTRICAL DATA
Line voltage data - 60hz 208/230V-1ph208/230V-1ph 208/230V-1ph
3
Maximum overcurrent protection (amps) 40 40 50
4
Minimum circuit ampacity 25 25.8 30.4
Compressor Rated load amps15.918.
52
2.2
Locked rotor amps112.3 12
41
27.9
Power factor 0.99 0.99 0.99
Outdoor Fan Motor Full load amps2.6 2.
62
.6
CONTROLS
iComfort
®
E30 Smart Wi-Fi Thermostat 15S63 •••
Remote Outdoor Temperature Sensor X2658 •••
OPTIONAL ACCESSORIES - ORDER SEPARATELY
Compressor Hard Start Kit Copeland 10J42 ••
LG 88M91
••
Compressor Low Ambient Cut-Off 45F08 •••
Freezestat 3/8 in. tubing 93G35 •••
5/8 in. tubing 50A93 •••
Indoor Blower Off Delay Relay 58M81 •••
Loss of Charge Switch Kit 84M23 •••
5
Low Ambient Kit 54M89 •••
Mild Weather Kit 11B97 •••
Monitor Kit - Service Light 76F53 •••
Outdoor Thermostat Kit Thermostat 10Z23 •••
Mounting Box 31461 •••
Refrigerant
Line Sets
L15-65-30 L15-65-40
L15-65-50
••
6
Snow Guard 39-1/2 x 35-5/8 in. Y1033 •••
NOTE - Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Sound Rating Number rated in accordance with test conditions included in AHRI Standard 270.
2
additional refrigerant charge required.
3
HACR type breaker or fuse.
4
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
5
Crankcase Heater and Freezestat are recommended with Low Ambient Kit.
6
Add 11-1/2 inches (292 mm) to unit height.
