Lennox iHarmony 10C16 Installation Instructions

15
Table 13. Alert Codes and Troubleshooting
Initial notication of critical alerts will pop up on the home screen and will be listed under notication menu. Minor and moderate alerts are found only
under the notication menu.
Alert
Code
Priority
Condition
Actual
Displayed Alert
Text
Component or System Operational State and Troubleshooting Tip
How to clear
alert code
131 Critical
Corrupted
Control
Parameters
System component control parameters are corrupted.
• Replace the system component control if heating or cooling is not available.
• Go to menu > advance settings > view dealer control center >
equipment and press reset all equipment. This will allow the system to
auto-detect any iComfort components attached.
Will automatically
clear when system
component (device)
passes memory
self-test or system
component control is
replaced.
132 Critical
Failed Flash CRC
Check
System component control software is corrupted.
• Recycle power.
• If failure re-occurs, replace the system component control.
Manual system power
reset is required to
recover from this alert
code.
250 Moderate
Primary Limit
Switch Open
The furnace primary limit switch is open.
• If limit switch is not closed within three minutes, the unit will go into a 60
minute soft lockout (WatchGuard mode).
• Check for high gas pressure.
• Low supply air due to being plugged or restriction in system (example:
dirty air lter or blockage in duct work).
• Limit trips will place the iHarmony zoning system into non-zone mode.
• Check for proper ring rate on furnace.
• Check for non-functioning zone dampers.
NOTE: Refer to S&A Note ACC-14-01 - iHarmony and SLP98 - Insufcient
Zone Heating and Alarm Code 250 Issues for corrective actions.
Automatically clears
when a heat call ends
successfully.
NOTE: If this issue
occurred on an
iHarmony zoning
system, the eld will
need to manually
activate the zoning.
310 Moderate
Discharge Air
Temp Sensor
Problem
There is a discharge air temperature sensor issue.
• Compare discharge temperature sensor (DATS) resistance to temperature
/ resistance charts in system component installation instruction.
• Replace discharge air sensor if necessary.
NOTE: Conrm there is no short or open circuits in the iComfort thermostat
connections to any of the other components in the communication
system.
NOTE: Issues with a DATS connected to a damper control module or equip-
ment interface model will not generate an alert code.
Automatically clears
30 seconds after
condition is detected
as recovered or after
system restart.
530
Moderate /
Critical
Low Damper
24VAC Voltage
Low Damper 24VAC Voltage
• Damper supply voltage is less than 18VAC.
• Maintain non-zone mode for ve minutes after alarm clears.
Automatically clears
when the condition no
longer exists.
532 Moderate
Zoning Pressure
Switch Opened
(High Pressure)
Zoning Pressure Switch Opened (high pressure)
• Compressor pressure is above the specied limit.
• Compressor is turned off.
• Zoning will be restored once the high pressure switch closes.
Automatically clears
after compressor
pressure is within
limits.
542
Moderate/
Critical
Zone 1
Temperature
Sensor Problem
• Zone temperature sensor reading out of range.
• Open or short zone temperature sensor detected for more than ve
second.
• Damper control module will operate in non-zone mode (all dampers open)
– moderate condition.
• If after 10 minutes the condition does not change, the priority code is
change to critical. System will continue to operate in non-zone mode.
Automatically clears
30 seconds after
condition no longer
exist.
543
Moderate/
Critical
Zone 2
Temperature
Sensor Problem
544
Moderate/
Critical
Zone 3
Temperature
Sensor Problem
545
Moderate/
Critical
Zone 4
Temperature
Sensor Problem
