Installer Checklist
Table 5. Installation Checklist
Item Description Yes No
1 Is the zone sensor properly mounted to either a wall stud or wall? (Do not mount on exterior wall or near any
ventilation outputs, doorways or location that could be directly exposed to sunlight)
2 Are all terminals wiring properly connected and tight?
4 Have all the zone sensor features been explained to the homeowner?
5 Has user manual been given to homeowner?
6 Was the correct thermostat wiring gauge used?
7 Are unused thermostat wires (conductors) wired together to minimize electrical interference that could affect
electronic components in the zone sensor. (See “Figure 3. Communicating and Low Voltage Connections”
on page 7.)
8 Was the hole in the wall sealed with a suitable material to prevent drafts from entering the zone sensor case.
Not doing so could affect the zone sensor internal temperature sensor.
9 Did the address get set correctly during initial power up of the zone sensor?
10 When replacing an existing zone sensor did you set the address of the new or relocated zone sensor to
match the address of the zone sensor being replaced?
