• 23 •
PE
A1
M1
XA1
Installation, operation and maintenance /
INAL
TO-IOM-1809-E
Size 05 to 15
LEGEND:
Earth (yellow/green)
Electronic control
Motor
T
erminal board
Pic. 35
EC MOTOR
F
AN SPEED CONTROL
0-10 Vdc
2x0,5mmq
POWER SUPPL
Y
PERMANENT
230V
ac/50Hz
3x1mmq
WIRING DIAGRAM
23
25
Table of Contents
Table of Contents
2
General Description
3
Fittings 4 Rows Coil
4
Fittings 4 Rows Coil
5
Installation
6
Example of Accessories Use and Compatibility
7
Assembly Diagrams
8
EC Motor
24
Turning the Coil
30
Dismantling the Unit
31
4
