• 7 •
Installation, operation and maintenance / INALTO-IOM-1809-E
SUPPLY PLENUM (PAM)
INTAKE PLENUM (PAM)
Size 05 to 28
x8 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl anged with corrugated washer DIN4161
Sizes 49 & 57
x10 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl angiato with corrugated washer DIN4161
Size 05 to 28
x8 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl anged with corrugated washer DIN4161
Sizes 49 & 57
x10 Screw TC+M5x12 UNI7687
x6 Hex nut M5 fl anged with corrugated washer DIN4161
Figure 07
Figure 08
ASSEMBLY DIAGRAMS
