9.4 EC fans
Tab. 9 AESP (Pa) with the different control tensions (0 - 10 V) for the EC fan(s)
DMADR 060 1 V 2 V 3 V 4 V 5 V 6 V 7 V 8 V 9 V 10 V
Basic + Filter - - - - - 45 178 312 445 578
Basic + Filter + Heater - - - - - 35 168 302 435 568
Basic + Filter + Add coil - - - - - 28 161 295 428 561
Free Cooling + Filter - - - - - 25 158 292 425 558
Free Cooling + Filter + Heater - - - - - 15 148 282 415 548
Free Cooling + Filter + Add coil - - - - - 8 141 275 408 541
DMADR 080 1 V 2 V 3 V 4 V 5 V 6 V 7 V 8 V 9 V 10 V
Basic + Filter - - - - - - 119 260 400 541
Basic + Filter + Heater - - - - - - 107 248 388 529
Basic + Filter + Add coil - - - - - - 95 236 376 517
Free Cooling + Filter - - - - - - 91 232 372 513
Free Cooling + Filter + Heater - - - - - - 79 220 360 501
Free Cooling + Filter + Add coil - - - - - - 67 208 318 489
DMADR 100 / 110 1 V 2 V 3 V 4 V 5 V 6 V 7 V 8 V 9 V 10 V
Basic + Filter - - - - - - - 144 308 473
Basic + Filter + Heater - - - - - - - 129 293 458
Basic + Filter + Add coil - - - - - - - 126 290 455
Free Cooling + Filter - - - - - - - 110 274 439
Free Cooling + Filter + Heater - - - - - - - 95 259 424
Free Cooling + Filter + Add coil - - - - - - - 92 256 421
DMADR 130 1 V 2 V 3 V 4 V 5 V 6 V 7 V 8 V 9 V 10 V
Basic + Filter - - - - - - - 93 260 426
Basic + Filter + Heater - - - - - - - 77 244 410
Basic + Filter + Add coil - - - - - - - 74 241 407
Free Cooling + Filter - - - - - - - 57 224 390
Free Cooling + Filter + Heater - - - - - - - 41 208 374
Free Cooling + Filter + Add coil - - - - - - - 38 205 371
DMADR 160 / 190 / 205 1 V 2 V 3 V 4 V 5 V 6 V 7 V 8 V 9 V 10 V
Basic + Filter - - - - - - - - - 148
Basic + Filter + Heater - - - - - - - - - 113
Basic + Filter + Add coil - - - - - - - - 103
Free Cooling + Filter - - - - - - - - - 94
Free Cooling + Filter + Heater - - - - - - - - - 59
Free Cooling + Filter + Add coil - - - - - - - - - 49
