Outdoor Unit Information
9.
Single and Multiple Zone Outdoor Units
NOTE:
Outdoor units can only be installed in an unenclosed outdoor environment.
9.1.
Model Number Identication
M P C 009 S 4 S - 1 P
Unit T
ype
L
= Low
Ambient Heat Pump
P = Heat Pump
Series T
ype
M = Mini-Split
Cooling Efciency
S = Standard Efciency
Major Design Sequence
A
= 1st Generation
B = 2nd Generation
C = 3rd Generation
Nominal Cooling Capacity
009 = 0.75 tons
012 = 1 tons
018 = 1.5 tons
024 = 2 tons
030 = 2.5 tons
036 = 3 tons
048 = 4 tons
Refrigerant T
ype
4 = R-410A
Refrigerant Circuits
S = Single Circuit
M = Multiple Circuits
Minor Design Sequence
1 = 1st Revision
V
oltage
L
= 1
15V
-1 phase-60hz
P = 208/230V
-1 phase-60hz
