Table 14. MLB048S4M

Number of Zones and Outdoor Unit Connection Sizes

NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit

Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)

1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas

009 009 009 018 - - -

009 009 009 024 - - -

009 009 009 030 - - -

009 009 009 036 - - -

009 009 012 012 - - -

009 009 012 018 - - -

009 009 012 024 - - -

009 009 012 030 - - -

009 009 018 018 - - -

009 009 018 024 - - -

009 012 012 012 - - -

009 012 012 018 - - -

009 012 012 024 - - -

009 012 012 030 - - -

009 012 018 018 - - -

009 012 018 024 - - -

012 012 012 012 - - -

012 012 012 018 - - -

012 012 012 024 - - -

012 012 018 018 - - -

009 009 009 009 009

009 009 009 009 012

009 009 009 009 018

009 009 009 009 024

009 009 009 012 012

009 009 009 012 018

009 009 009 012 024

009 009 012 012 012

009 009 012 012 018

009 012 012 012 012

012 012 012 012 012

LEGEND:

CLEAR = No adapters required.

GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).

BLACK = 1/4 x 3/8 in. liquid pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).

1/2 x 5/8 in. gas pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
