SPECIFICATIONS
Gas
Heating
Performance
Model No. ML195UH
090XP48C
ML195UH
110XP48C
ML195UH
110XP60C
ML195UH
135XP60D
1
AFUE 95% 95% 95% 95%
Input - Btuh 88,000 110,000 110,000 132,000
Output - Btuh 85,000 105,000 106,000 126,000
Temperature rise range - °F 40 - 70 50 - 80 40 - 70 45 - 75
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0 3.5 / 10.0 3.5 / 10.0
High static - in. w.g. 0.5 0.5 0.5 0.5
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 1/2 1/2 1/2 1/2
with furnished 90° street elbow 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 3/4 1 1
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 10 10 x 10 11-1/2 x 10 11-1/2 x 10
Motor output - hp 1/2 1/2 1 1
Tons of add-on cooling 3 - 4 3 - 4 4 - 5 4 - 5
Air Volume Range - cfm 900 - 2140 715 - 2000 1250 - 2485 1145 - 2595
Electrical
Data
Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 8.2 8.2 11.5 11.5
Maximum overcurrent protection 12 12 15 15
Shipping Data lbs. - 1 package 149 159 164 177
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Efciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
SPECIFICATIONS
Gas
Heating
Performance
Model No. ML195UH
045XP24B
ML195UH
045XP36B
ML195UH
070XP36B
ML195UH
090XP36C
1
AFUE 95% 95% 95% 95%
Input - Btuh 44,000 44,000 66,000 88,000
Output - Btuh 41,000 42,000 64,000 85,000
Temperature rise range - °F 40 - 70 25 - 55 40 - 70 50 - 80
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0 3.5 / 10.0 3.5 / 10.0
High static - in. w.g. 0.5 0.5 0.5 0.5
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 1/2 1/2 1/2 1/2
with furnished 90° street elbow 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt 1/2 slip x 1/2 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 3/4 3/4 3/4
Indoor
Blower
Wheel nom. dia. x width - in. 10 x 8 10 x 8 10 x 8 10 x 8
Motor output - hp 1/3 1/3 1/3 1/3
Tons of add-on cooling 2.5 - 3 2 - 3 2.5 - 3 2 - 3
Air Volume Range - cfm 390 - 1140 700 - 1605 650 - 1585 655 - 1630
Electrical
Data
Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 3.1 6.1 6.1 6.1
Maximum overcurrent protection 12 12 12 12
Shipping Data lbs. - 1 package 119 121 129 144
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Efciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
