Table 5. MLB and MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MLB036S4M
and
MPC036S4M
2
18K 6K - - - - - - - - - 18,000 6,000 - - - - - - - - - 19,100 6,400 - - - - - - - - -
24K 6K - - - - - - - - - 22,000 6,000 - - - - - - - - - 24,200 6,100 - - - - - - - - -
18K 9K - - - - - - - - - 17,000 9,000 - - - - - - - - - 18,700 9,400 - - - - - - - - -
24K 9K - - - - - - - - - 21,000 8,000 - - - - - - - - - 23,300 8,800 - - - - - - - - -
12K 12K - - - - - - - - - 12,000 12,000 - - - - - - - - - 12,800 12,800 - - - - - - - - -
18K 12K - - - - - - - - - 17,000 11,000 - - - - - - - - - 18,200 12,100 - - - - - - - - -
24K 12K - - - - - - - - - 20,000 10,000 - - - - - - - - - 22,200 11,100 - - - - - - - - -
18K 18K - - - - - - - - - 15,000 15,000 - - - - - - - - - 16,600 16,600 - - - - - - - - -
24K 18K - - - - - - - - - 18,000 13,000 - - - - - - - - - 19,300 14,500 - - - - - - - - -
24K 24K - - - - - - - - - 15,000 15,000 - - - - - - - - - 15,700 15,700 - - - - - - - - -
3
12K 6K 6K - - - - - - 12,900 6,500 6,500 - - - - - - 13,600 6,800 6,800 - - - - - -
18K 6K 6K - - - - - - 18,000 6,000 6,000 - - - - - - 18,900 6,300 6,300 - - - - - -
24K 6K 6K - - - - - - 22,000 5,500 5,500 - - - - - - 23,200 5,800 5,800 - - - - - -
12K 9K 6K - - - - - - 12,500 9,300 6,200 - - - - - - 13,100 9,800 6,600 - - - - - -
18K 9K 6K - - - - - - 17,200 8,600 5,700 - - - - - - 18,100 9,100 6,100 - - - - - -
24K 9K 6K - - - - - - 21,100 7,900 5,300 - - - - - - 22,200 8,400 5,600 - - - - - -
12K 12K 6K - - - - - - 12,000 12,000 6,000 - - - - - - 12,600 12,600 6,300 - - - - - -
18K 12K 6K - - - - - - 16,500 11,000 5,500 - - - - - - 17,400 11,600 5,800 - - - - - -
24K 12K 6K - - - - - - 20,100 10,000 5,000 - - - - - - 21,200 10,600 5,300 - - - - - -
18K 18K 6K - - - - - - 15,100 15,100 5,000 - - - - - - 15,900 15,900 5,300 - - - - - -
24K 18K 6K - - - - - - 18,100 13,600 4,500 - - - - - - 19,200 14,400 4,800 - - - - - -
9K 9K 9K - - - - - - 9,300 9,300 9,300 - - - - - - 9,800 9,800 9,800 - - - - - -
12K 9K 9K - - - - - - 12,000 9,000 9,000 - - - - - - 12,600 9,500 9,500 - - - - - -
18K 9K 9K - - - - - - 16,500 8,300 8,300 - - - - - - 17,400 8,700 8,700 - - - - - -
24K 9K 9K - - - - - - 20,100 7,500 7,500 - - - - - - 21,200 8,000 8,000 - - - - - -
12K 12K 9K - - - - - - 11,500 11,500 8,600 - - - - - - 12,100 12,100 9,100 - - - - - -
18K 12K 9K - - - - - - 15,800 10,500 7,900 - - - - - - 16,700 11,100 8,400 - - - - - -
24K 12K 9K - - - - - - 19,100 9,600 7,200 - - - - - - 20,200 10,100 7,600 - - - - - -
18K 18K 9K - - - - - - 14,300 14,300 7,200 - - - - - - 15,200 15,200 7,600 - - - - - -
12K 12K 12K - - - - - - 11,000 11,000 11,000 - - - - - - 11,600 11,600 11,600 - - - - - -
18K 12K 12K - - - - - - 15,100 10,000 10,000 - - - - - - 15,900 10,600 10,600 - - - - - -
24K 12K 12K - - - - - - 18,100 9,100 9,100 - - - - - - 19,200 9,600 9,600 - - - - - -
18K 18K 12K - - - - - - 13,600 13,600 9,100 - - - - - - 14,400 14,400 9,600 - - - - - -
4
6K 6K 6K 6K - - - 7,200 7,200 7,200 7,200 - - - 7,700 7,700 7,700 7,700 - - -
9K 6K 6K 6K - - - 10,400 6,900 6,900 6,900 - - - 11,000 7,400 7,400 7,400 - - -
12K 6K 6K 6K - - - 13,200 6,600 6,600 6,600 - - - 14,000 7,000 7,000 7,000 - - -
18K 6K 6K 6K - - - 17,900 6,000 6,000 6,000 - - - 19,000 6,400 6,400 6,400 - - -
24K 6K 6K 6K - - - 21,400 5,300 5,300 5,300 - - - 22,600 5,700 5,700 5,700 - - -
9K 9K 6K 6K - - - 9,900 9,900 6,600 6,600 - - - 10,500 10,500 7,000 7,000 - - -
12K 9K 6K 6K - - - 12,600 9,400 6,300 6,300 - - - 13,300 10,000 6,700 6,700 - - -
18K 9K 6K 6K - - - 17,000 8,500 5,700 5,700 - - - 18,000 9,000 6,000 6,000 - - -
24K 9K 6K 6K - - - 20,100 7,500 5,000 5,000 - - - 21,200 8,000 5,300 5,300 - - -
12K 12K 6K 6K - - - 12,000 12,000 6,000 6,000 - - - 12,700 12,700 6,400 6,400 - - -
18K 12K 6K 6K - - - 16,000 10,700 5,300 5,300 - - - 17,000 11,300 5,700 5,700 - - -
24K 12K 6K 6K - - - 18,900 9,400 4,700 4,700 - - - 19,900 10,000 5,000 5,000 - - -
9K 9K 9K 6K - - - 9,400 9,400 9,400 6,300 - - - 10,000 10,000 10,000 6,700 - - -
12K 9K 9K 6K - - - 12,000 9,000 9,000 6,000 - - - 12,700 9,500 9,500 6,400 - - -
18K 9K 9K 6K - - - 16,000 8,000 8,000 5,300 - - - 17,000 8,500 8,500 5,700 - - -
24K 9K 9K 6K - - - 18,900 7,100 7,100 4,700 - - - 19,900 7,500 7,500 5,000 - - -
12K 12K 9K 6K - - - 11,300 11,300 8,500 5,700 - - - 12,000 12,000 9,000 6,000 - - -
18K 12K 9K 6K - - - 15,100 10,100 7,500 5,000 - - - 15,900 10,600 8,000 5,300 - - -
12K 12K 12K 6K - - - 10,700 10,700 10,700 5,300 - - - 11,300 11,300 11,300 5,700 - - -
18K 12K 12K 6K - - - 14,100 9,400 9,400 4,700 - - - 14,900 10,000 10,000 5,000 - - -
9K 9K 9K 9K - - - 9,000 9,000 9,000 9,000 - - - 9,500 9,500 9,500 9,500 - - -
12K 9K 9K 9K - - - 11,300 8,500 8,500 8,500 - - - 12,000 9,000 9,000 9,000 - - -
18K 9K 9K 9K - - - 15,100 7,500 7,500 7,500 - - - 15,900 8,000 8,000 8,000 - - -
12K 12K 9K 9K - - - 10,700 10,700 8,000 8,000 - - - 11,300 11,300 8,500 8,500 - - -
18K 12K 9K 9K - - - 14,100 9,400 7,100 7,100 - - - 14,900 10,000 7,500 7,500 - - -
12K 12K 12K 9K - - - 10,100 10,100 10,100 7,500 - - - 10,600 10,600 10,600 8,000 - - -
12K 12K 12K 12K - - - 9,400 9,400 9,400 9,400 - - - 10,000 10,000 10,000 10,000 - - -
