Lennox Mini-Split Service Manual / Page 26
SPECIFICATIONS - CASSETTE INDOOR UNITS - M33A024-048
Model No. M33A024S4-1P M33A036S4-1P M33A048S4-1P
Nominal Tons 2 3 4
Power Supply - 60 hz - 1 phase 208/230V 208/230V 208/230V
Rated load amps 2 1.5 1.6
Output (W) 42 124 124
Air Volume - cfm (High/Medium/Low) 820/740/590 1060/940/820 1190/1000/850
Sound Data (dBA) - Low/Medium/High 43/47/51 44/47/52 44/48/52
Piping Connections - Liquid/Gas - o.d. - fl are - in. 3/8 / 5/8 3/8 / 5/8 3/8 / 5/8
Drain connection o.d. - in. 1-1/4 1-1/4 1-1/4
Net/Shipping weights - lbs. Body 46 / 53 56 / 63 64 / 74
REQUIRED COMPONENTS - ORDERED SEPARATELY
Cassette Panel 13X05 (M0STAT63Q-1) 13X05 (M0STAT63Q-1) 13X05 (M0STAT63Q-1)
Net/Shipping weights - lbs. 12 / 18 12 / 18 12 / 18
