TP − 3 to 5 Ton R−22 Heat Pump Outdoor Units / Page 6
SPECIFICATIONS
General
Model No. TPA036S2 TPA048S2 TPA060S2
Data
Nominal Tonnage (kW) 3 (10.6)
4 (14.1) 5 (17.6)
Connections
Liquid line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Vapor line o.d. − in. (mm) 7/8 (22.2)
7/8 (22.2) 1-1/8 (28.6)
2
Refrigerant R−22 charge furnished 8 lbs. 10 oz.
(3.91 kg)
11 lbs. 12 oz.
(5.33 kg)
14 lbs. 0 oz.
(6.35 kg)
Outdoor
Net face area
Outer coil 15.21 (1.41) 21.11 (1.96) 24.94 (2.32)
Coil sq. ft. (m
)
Inner coil 14.50 (1.35)
20.31 (1.89) 24.13 (2.24)
Tube diameter − in. (mm) no. of rows 5/16 (8) − 2 5/16 (8) − 2 5/16 (8) − 2
Fins per inch (m) 22 (866) 22 (866) 22 (866)
Outdoor
Diameter − in. (mm) − No. of Blades 18 (457) − 4 22 (559) − 4 26 (660) − 4
Fan
Motor hp (W) 208/230V − 1/5 (149)
460V − 1/6 (124)
1/3 (249) 1/3 (249)
Cfm (L/s) 2450 (1155) 3890 (1835) 4550 (2145)
Rpm 1100 1085 830
Watts 190 375 307
Shipping Data − lbs. (kg) 1 package 178 (81) 248 (112) 284 (129)
ELECTRICAL DATA
Line voltage data − 60 hz − 3ph 208/230V 460V 208/230V 460V 208/230V 460V
3
Maximum overcurrent protection (amps) 20 10 30 15 40 15
4
Minimum circuit ampacity 13.1 6.5 20.0 9.5 23.4 10.1
Compressor
Rated Load Amps
9.6 4.8 14.7 7.0 17.3 6.7
Locked Rotor Amps
77
35 91 50 123 49.5
Power Factor
.96
.88 .96 .87 .96 .88
Outdoor
Full Load Amps
1.1 .55 1.7 .82 1.8 .9
Fan Motor
Locked Rotor Amps
1.9
1.1 4.1 2.2 2.9 2.3
OPTIONAL ACCESSORIES − must be ordered extra
Compressor Low Ambient Cut−Off 45F08 S S S
Compressor Sound Cover 69J03 S S S
Freezestat
3/8 in. tubing 93G35 S S S
5/8 in. tubing 50A93 S S S
Hail Guards
92M89 S
92M90 S
27W36 S
High Pressure Switch Kit 94J46 S S S
Loss of Charge Kit 84M23 S S S
5
Low Ambient Kit (down to 30°F) 27J00 S S S
Low Ambient Control Option (down to 0°F) See table page 7 See table page 7 See table page 7
Mild Weather Kit 33M07 S S S
Monitor Kit − Service Light 76F53 S S S
Mounting Base
69J06 S
69J07 S S
Outdoor
Thermostat 56A87 S S S
ermos
a
Kit
Mounting Box 31461 S
S S
Refrigerant
L15−65−30, L15−65−40, or L15−65−50 S S
Line Sets
Field Fabricate
S
Time Delay Relay Kit 58M81 S S S
Unit Stand−Off Kit 94J45 S S S
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Sound Rating Number rated in accordance with test conditions included in ARI Standard 270.
2
Refrigerant charge sufficient for 15 ft. length of refrigerant lines.
3
HACR type circuit breaker or fuse.
4
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
5
Freezestat is recommended with Low Ambient Kit.
