Lennox TSA036S4 User Manual

TS − 3 to 5 Ton R−410A Air Conditioners / Page 6
SPECIFICATIONS
General
Dt
Model No. TSA036S4 TSA042S4 TSA048S4 TSA060S4
Data
Nominal Tonnage 3
3.5 4 5
Connections
(sweat)
Liquid line o.d. − in. 3/8 3/8 3/8 3/8
(sweat)
Suction line o.d. − in. 7/8
7/8 7/8 1-1/8
1
Refrigerant (R-410A) furnished 5 lbs. 9 oz. 8 lbs. 3 oz. 8 lbs. 4 oz. 10 lbs. 0 oz.
Outdoor
Coil
Net face
area sq ft
Outer coil
13.22 15.11 16.32 21.00
Coil area - sq. ft.
Inner coil
− − −
14.40 15.71 20.25
Tube diameter − in. 5/16 5/16 5/16 5/16
Fins per inch − No. of rows 26 − 1 22 − 2 22 − 2 22 − 2
Outdoor
Fan
Diam. − in. − No. of blades 18 − 4 18 − 4 22 − 4 22 − 4
Fan
Motor hp 208/230V − 1/5
460V − 1/6
1/3 1/4 1/4
Cfm 2400 2930 3500 3830
Rpm 1090 1100 825 825
Watts 185 310 320 330
Shipping Data − lbs. 1 package 135 177 200 222
ELECTRICAL DATA
Line voltage data − 60 hz − 3ph 208/230V 460V 208/230V 460V 208/230V 460V 575V 208/230V 460V 575V
2
Maximum overcurrent protection (amps) 20 15 30 15 30 15 15 35 15 15
3
Minimum circuit ampacity 14.2 7.8 18.6 8.4 18.8 8.8 7.0 21.3 10.7 8.3
Compressor
Rated load amps
10.4 5.8 13.5 6.0 13.7 6.2 4.8 15.6 7.8 5.8
Power factor
.85
.84 .83 .81 .90 .92 .88 .90 .91 .90
Locked rotor amps
73
38 88 44 83.1 41 30.4 110 52 35.5
Outdoor
Fan Motor
Full load amps
1.1 .55 1.7 1.0 1.7 1.0 1.0 1.7 1.0 1.0
Fan Motor
Locked rotor amps
1.9
1.1 4.1 2.2 3.1 2.3 2.3 3.1 2.3 2.3
OPTIONAL ACcESSORIES − must be ordered extra
Compressor Low Ambient Cut−Off 45F08 S S S S
Compressor Sound Cover 69J03 S S S S
Compressor Time−Off Control 47J27 S S S S
Freezestat
3/8 in. tubing 93G35 S S S S
5/8 in. tubing 50A93 S S S S
Hail Guards
92M88 S
92M89 S
92M92 S
92M90 S
Loss of Charge Kit 84M23 S S S S
4
Low Ambient Kit (down to 30°F) 34M72 S S S S
Mounting Base
69J06 S S
69J07 S S
Refrigerant
Line Sets
L15−65−30, L15−65−40,
L15−65−50
S S S
Field Fabricate S
Time Delay Relay Kit 58M81 S S S S
Unit Stand−Off Kit 94J45 S S S S
NOTE  Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufficient for 15 ft. length of refrigerant lines.
2
HACR type circuit breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
Freezestat is recommended with Low Ambient Kit.
