Lennox VRF VVCA Series User Manual

4
Clearances
Parts Identication
Horizontal Drain Pan
Gas Line Connection
Liquid Line Connection
Electronic Expansion Valve (EXV)
Strainer
Primary Drain Connection
Vertical Drain Pan
Auxiliary Horizontal
Auxiliary Upflow
Straps
Drip Shield
Baffle
Drain Connection
Drain Connection
Model No. 18-36 48-54
Cabinet 0 inch (0 mm) 0 inch (0 mm)
To Plenum 0 inch (0 mm) 0 inch (0 mm)
To Outlet Duct within 3 feet (914 mm) 0 inch (0 mm) 0 inch (0 mm)
Service / Maintenance See Note #1
1
Front service access - 24 inches (610 mm) minimum.
