Lenovo 100e Chromebook 2nd Gen User Manual

• The system board is sensitive to and can be damaged by ESD. Before touching it, establish personal
grounding by touching a ground point with one hand or by using an ESD strap (P/N 6405959).
Disabling the built-in battery
Before replacing any FRU, ensure that you disable the built-in battery.
To disable the built-in battery, press
together with the power button for about five seconds, and at the
same time detach the ac power adapter from the Chromebook.
Note: Power supply from the built-in battery will resume after you reconnect the Chromebook to the ac
power adapter.
1010 Base cover assembly
Removal steps of the base cover assembly
Loosen 9 screws that secure the base cover assembly.
Screw (quantity) Color
M2.5 × 6 mm, flat-head, nylon-coated (9)
Black
34 Lenovo 100e Chromebook 2nd Gen Hardware Maintenance Manual

Lenovo 100e Chromebook 2nd Gen Specifications

General

Storage	32GB eMMC
Operating System	Chrome OS
Battery Life	Up to 10 hours
Battery	42Wh
Camera	720p HD
RAM	4GB LPDDR3
Display	11.6" HD (1366 x 768)
Weight	1.2 kg
Dimensions	290 x 204 x 19.9 mm (11.41 x 8.03 x 0.78 inches)
Ports	microSD card reader, Headphone / mic combo
Wireless	WiFi 802.11 ac, Bluetooth 4.2
Keyboard	Spill-resistant
Processor	MediaTek MT8173C Processor (4 Cores, 4 Threads, 1.70 GHz)
