Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 18. Remove the battery pack cable
Step 2. Remove one screw and slide the solid-state drive out of the slot.
Figure 19. Remove one screw and slide the solid-state drive out of the slot
Screw specifications
Number of screws
M2 x 2.5 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Solid-state drive
38
IdeaPad 3 (14", 05), IdeaPad 3 (15", 05), and IdeaPad 3 (17", 05) Hardware Maintenance Manual
