Step 2. Disconnect the Wi-Fi card cables from the Wi-Fi card. Then, remove one screw and slide the Wi-Fi
card out of the slot.
Figure 25. Remove one screw and slide the Wi-Fi card out of the slot
Screw specifications Number of screws
M2 x 2.5 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Wi-Fi card
Remove the I/O board
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable, speaker cable, and the I/O board cable.
42
IdeaPad 3 (14", 05), IdeaPad 3 (15", 05), and IdeaPad 3 (17", 05) Hardware Maintenance Manual
