Lenovo 14ARE05 User Manual

Step 1. Remove 8 screws.
Figure 45. Remove 8 screws
Screw specifications
Number of screws
M2 x 2.2 8
Step 2. Remove hinges.
Figure 46. Remove hinges
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Hinges
LCD cover
Chapter 4. Removing a FRU or CRU 55

Lenovo 14ARE05 Specifications

General

Model	Lenovo 14ARE05
Category	Laptop
Processor	AMD Ryzen 5 4500U
RAM	8GB DDR4
Graphics	Integrated AMD Radeon Graphics
Operating System	Windows 10 Home
Weight	1.5 kg
Display	14-inch FHD (1920 x 1080) IPS
Battery	Up to 10 hours
Ports	HDMI, SD card reader
Wireless	Bluetooth 5.0
