Remove the battery pack
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 7. Disconnect the battery pack cable
Step 2. Remove four screws and then remove the battery pack.
Figure 8. Remove the battery pack
Chapter 4. Removing a FRU or CRU 31
