Step 2. Remove four screws.
Figure 10. Remove four screws
Screw specifications Number of screws
M2 x 5 4
Step 3. Disconnect the storage drive cable and remove the storage drive with bracket.
Figure 11. Disconnect the storage drive cable and remove the storage drive with bracket
Chapter 4. Removing a FRU or CRU 33
