Lenovo 3000 N500 User Manual

Table 34. Parts list—Overall (continued)
No. FRU FRU no. RoHS
ID
CRU
ID
14 SATA Hard disk drive assembly, 120 GB 5,400 rpm
v 4233-CTO
43N8391 R *
14 SATA Hard disk drive assembly, 160 GB 5,400 rpm
v 4233-CTO, 32x, 33x, 34x, 35x, 36x, 38x, 39x, 3Ax, 3Bx
43N8393 R *
14 SATA Hard disk drive assembly, 160 GB 5,400 rpm
v 4233-CTO, 32x, 33x, 34x, 35x, 36x, 38x, 39x, 3Ax, 3Bx
43N8394 R *
14 SATA Hard disk drive assembly, 160 GB 5,400 rpm
v 4233-CTO, 32x, 33x, 34x, 35x, 36x, 38x, 39x, 3Ax, 3Bx
43N8395 R *
14 SATA Hard disk drive assembly, 250 GB 5,400 rpm
v 4233-CTO, 37x, 3Cx, 3Dx, 3Ex
43N8397 R *
14 SATA Hard disk drive assembly, 250 GB 5,400 rpm
v 4233-CTO, 37x, 3Cx, 3Dx, 3Ex
43N8398 R *
14 SATA Hard disk drive assembly, 250 GB 5,400 rpm
v 4233-CTO, 37x, 3Cx, 3Dx, 3Ex
43N8399 R *
14 SATA Hard disk drive assembly, 320 GB 5,400 rpm
v 4233-CTO
43N8401 R *
14 SATA Hard disk drive assembly, 320 GB 5,400 rpm
v 4233-CTO
43N8403 R *
15 Base cover assembly 43N8370 R N
16 Speakers 43N8378 R N
17 Heat sink assembly (integrated)
v 4233-CTO, 32x, 33x, 34x, 35x, 36x, 37x, 38x, 39x, 3Ax,
3Bx, 3Cx
43N8373 R N
17 Heat sink assembly (discrete)
v 4233-CTO, 3Dx, 3Ex
43N8374 R N
18 Fan assembly 43N8375 R N
19 Intel WiFi Link 5100
v 4233-CTO, 32x, 33x, 34x, 35x, 36x, 37x, 38x, 39x, 3Ax,
3Bx, 3Cx, 3Dx, 3Ex
43Y6493 R **
19 Lenovo 802.11b/g Wireless LAN Mini-PCI Express
Adapter
v 4233-CTO
43Y6487 R **
19 Lenovo 802.11b/g Wireless LAN Mini-PCI Express
Adapter
v 4233-CTO
43Y6480 R **
20 Dummy cards 43N8382 R *
21 ExpressCard slot 43N8377 R N
22 Bluetooth daughter card (BDC-2) 43Y6491 R N
23 Keyboard (see “Keyboard” on page 103.)
— Thermal grease 91P8835 R N
— AC adapter (see “AC adapters” on page 105.)
100 Lenovo 3000 N500 Hardware Maintenance Manual

Lenovo 3000 N500 Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Pentium Mobile
Processor series	Intel Pentium T3000 Series for Mobile
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	13
Number of Processing Die Transistors	291 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Wireless technology	IEEE 802.11a/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	2 x 1 GB
Audio system	Conexant CX20561-12Z
Speaker power	2 W
Networking features	Ethernet/Fast Ethernet
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Cable lock slot type	IBM
Pointing device	Touchpad
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SLB3P
Processor ARK ID	35583

Weight and Dimensions

Depth	256.5 mm
Width	358.5 mm
Height	37 mm
Weight	2740 g
