Lenovo 3000 N500 User Manual

8. After you restart the computer, the computer prompts you for a supplemental
Rescue and Recovery disc. If you have a supplemental Rescue and Recovery
disc, click OK and insert the supplemental disc. If you do not have a
supplemental disc, click No.
9. When prompted, insert the appropriate Product Recovery disc and then click
OK. The second phase of the recovery process begins.
10. When all of the data has been copied from the last Product Recovery disc in
the set, a message is displayed prompting you to restart the computer.
Remove the disc and then click YES, then a message is displayed asking you
to continue the recovery process. Click Continue to restart your computer,
then the computer restarts and the third phase of the recovery process begins.
11. When the recovery process is complete, the Welcome to Microsoft Windows
screen is displayed. Follow the instructions on the screen to complete the
Windows setup.
Passwords
As many as three passwords may be needed for any Lenovo 3000 computer: the
power-on password (POP), the hard-disk password (HDP), and the supervisor
password (SVP).
If any of these passwords has been set, a prompt for it appears on the screen
whenever the computer is turned on. The computer does not start until the
password is entered.
Exception: If only an SVP is installed, the password prompt does not appear when
the operating system is booted.
Power-on password
A power-on password (POP) protects the system from being powered on by an
unauthorized person. The password must be entered before an operating system
can be booted.
Hard-disk password
There are two hard-disk passwords (HDPs):
v User HDP—for the user
v Master HDP—for the system administrator, who can use it to get access to the
hard disk even if the user has changed the user HDP
Note:
There are two modes for the HDP: User only and Master + User. The
Master + User mode requires two HDPs; the system administrator enters both in
the same operation. The system administrator then provides the user HDP to the
system user.
Attention:
If the user HDP has been forgotten, check whether a master HDP has
been set. If it has, it can be used for access to the hard disk drive. If no master
HDP is available, neither Lenovo nor Lenovo authorized servicers provide any
services to reset either the user or the master HDP, or to recover data from the
hard disk drive. The hard disk drive can be replaced for a scheduled fee.
32 Lenovo 3000 N500 Hardware Maintenance Manual

Lenovo 3000 N500 Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Pentium Mobile
Processor series	Intel Pentium T3000 Series for Mobile
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	13
Number of Processing Die Transistors	291 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Wireless technology	IEEE 802.11a/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	2 x 1 GB
Audio system	Conexant CX20561-12Z
Speaker power	2 W
Networking features	Ethernet/Fast Ethernet
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Cable lock slot type	IBM
Pointing device	Touchpad
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SLB3P
Processor ARK ID	35583

Weight and Dimensions

Depth	256.5 mm
Width	358.5 mm
Height	37 mm
Weight	2740 g
