Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock User Manual

Update the dock driver and firmware
The dock driver and firmware are preinstalled on compatible computers. The dock is ready for use after you
connect it to your computer and ac power.
It is recommended that you update the dock driver and firmware whenever a new version is available to
improve performance of the dock.
To update the dock driver and firmware:
1. Go to
https://www.lenovo.com/support/docks.
2. Select the entry for the dock and then follow the on-screen instructions to download and install the dock
driver and firmware.
3. The driver update takes effect when you restart your computer. The firmware update takes effect when
you reconnect the dock to your computer.
Install Lenovo Dock Manager
Lenovo Dock Manager is designed to provide silent firmware update and device information query.
To download Lenovo Dock Manager, go to
https://support.lenovo.com/us/en/solutions/ht037099.
8
ThinkPad Universal Thunderbolt 4 Dock ThinkPad Universal Thunderbolt 4 Smart Dock ThinkPad Thunderbolt 4 Workstation Dock
User Guide

Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock Specifications

General

DisplayPort version	1.4
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Connectivity technology	Wired
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Certification	cULus, FCC, ICES, NOM
Product color	Black
Data transfer rate	40 Gbit/s
Maximum refresh rate	60 Hz
Input current	6.75 A
Power source type	DC
Power consumption (max)	100 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Package depth	195 mm
Package width	270 mm
Package height	85 mm
Package weight	1230 g
Cables included	AC, Thunderbolt
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	80 mm
Width	220 mm
Height	30 mm
Weight	460 g
