Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock User Manual

Product overview
1
2
Power connector
Connect to ac power with the accompanying ac power adapter and power cord.
Thunderbolt
™
4 connector (for connecting computer)
Connect to your computer with the accompanying cable.
Thunderbolt 4 connector
Connect a compatible device to
• Transfer data.
• Charge with the output voltage and current of up to 5 V and 3 A.
• Connect an external display with a Thunderbolt cable or USB-C cable.
Note: Do not connect your computer to this connector.
DisplayPort
®
connectors
Connect to external displays with DisplayPort cables.
USB 3.2 connector Gen 2
Connect a compatible device to transfer data.
Ethernet connector
Connect to a LAN with an Ethernet cable.
Chapter 1. About the dock 3

Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock Specifications

General

DisplayPort version	1.4
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Connectivity technology	Wired
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Certification	cULus, FCC, ICES, NOM
Product color	Black
Data transfer rate	40 Gbit/s
Maximum refresh rate	60 Hz
Input current	6.75 A
Power source type	DC
Power consumption (max)	100 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Package depth	195 mm
Package width	270 mm
Package height	85 mm
Package weight	1230 g
Cables included	AC, Thunderbolt
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	80 mm
Width	220 mm
Height	30 mm
Weight	460 g
