Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock User Manual

Chapter 3. Use the dock
Use the video output connectors
The dock has four video output connectors to support up to four external displays:
• One Thunderbolt 4 connector (support DisplayPort 1.4 and Thunderbolt 4)
• Two DisplayPort connectors (support DisplayPort 1.4)
• One HDMI connector (supports HDMI 2.1)
Supported resolutions
Depending on the USB-C connector or Thunderbolt connector on your computer, the dock supports the
following display resolutions:
• One video output connector: up to 7680 x 4320 pixels / 30 Hz (HDMI only)
• Two video output connectors: up to 7680 x 4320 pixels / 30 Hz (HDMI only) and 5120 x 2880 pixels / 60
Hz (Thunderbolt 4 only)
• Three video output connectors: up to 3840 x 2160 pixels / 60 Hz
• Four video output connectors: up to 3840 x 2160 pixels / 60 Hz
To view the maximum display matrix, go to
https://www.lenovo.com/support/docks and select the entry for the
dock.
Configure the external displays
You can configure the external displays connected to your dock:
• Set the display mode: extend, mirror or duplicate, or single display.
• Set the orientation, brightness, resolution, color, and more.
To configure the external displays:
1. Right-click a blank area on the desktop and select Display settings.
2. Select the display that you want to configure.
3. Configure display settings of your preference.
For more information, see the Windows help information.
Use the Ethernet connector
You can use the Ethernet connector on the dock to connect your computer to a standard 10 Mbps, 100
Mbps, or 1000 Mbps network with an Ethernet cable.
The Ethernet connector has two network status indicators. When the green indicator is on, the computer is
connected to a LAN. When the yellow indicator blinks, data is being transmitted.
Depending on your computer, some of the following functions are available when the dock is connected to a
LAN.
• Preboot eXecution Environment
© Copyright Lenovo 2021 9

Lenovo ThinkPad Universal Thunderbolt 4 Smart Dock Specifications

General

DisplayPort version	1.4
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
Connectivity technology	Wired
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Certification	cULus, FCC, ICES, NOM
Product color	Black
Data transfer rate	40 Gbit/s
Maximum refresh rate	60 Hz
Input current	6.75 A
Power source type	DC
Power consumption (max)	100 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Package depth	195 mm
Package width	270 mm
Package height	85 mm
Package weight	1230 g
Cables included	AC, Thunderbolt
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	80 mm
Width	220 mm
Height	30 mm
Weight	460 g
