Thefollowingillustrationshowsthefrontviewoftheserver.
Figure3.Frontviewoftheserver
1Opticaldriveeject/closebutton
4Powerbutton
2HarddiskdriveactivityLED
5USB3.0connectors(2)
3Power-onLED
Rearviewoftheserver
Thistopicprovidesinformationtohelpyoulocatetheconnectorsandcomponentsontherearofyourserver.
Figure4“Rearconnectorlocations”onpage15
showsthelocationsoftheconnectorsontherearof
yourserver.Someconnectorsontherearofyourserverarecolor-codedtohelpyoudeterminewhere
toconnectthecablesonyourserver.
14ThinkServerTS140HardwareMaintenanceManual
