The modular system
Values printed in bold are standard designs. Values that are not printed in bold
are potenal extensions, some of them including a surcharge.
Geared motors up to 660 Nm
Gearbox g500-S130 g500-S220 g500-S400 g500-S660
Min. motor assignment m850-S120 m850-S120 m850-S120 m850-S120
Max. motor assignment m850-S120 m850-S140 m850-S140 m850-S190
Technical data
Max. output torque Nm 130 220 400 660
Min. drive torque Nm 4.8 4.8 4.8 4.8
Max. drive torque Nm 7.4 14 17.4 35
Mounng posion
Standard M1, M2, M3, M4, M5, M6 (ABCDEF)
Combined M1/5/6 (AEF)
Color Primed
Painted in RAL colors
Surface and corrosion protecon OKS-G
Dierent types of OKS
Output sha
Solid sha with featherkey (V) mm 25 x 50 25 x 50 30 x 60 35 x 70
40 x 80
Hollow sha with keyway (H) mm 25 25/30 30/35 40/45
Hollow sha with shrink disc (S) mm 25 25/30 35 40
Sha material Steel
Stainless steel
Sha sealing ring material NBR
FKM (Viton)
Output sha bearing Normal
Gearbox version With foot (HBR/VBR)
Without foot and centring (HCR)/(VCR/SCR)
With centring (HCR/VCR/SCR)
With output ange (HCK/VCK/SCK)
Output ange (K) mm 160 160 200 200/250
Lubricant Synthec oil
Food-compable oil
Venlaon Without Vent valve
Cooling Self-venlated
Torque plate Rubber buers
Sha cover Shrink disc cover
Motor connecon Connector
ICN hybrid connector for One Cable Technology (OCT)
Permanent magnet holding brake Without
With
Feedback
Without funconal safety Resolver
Absolute value encoder
Digital absolute value encoder for One Cable Technology (OCT))
With funconal safety Resolver
Absolute value encoder
Digital absolute value encoder for One Cable Technology (OCT)
Temperature monitoring PT1000 temperature sensor
Product informaon
The modular system
10
