Product codes
Gearbox product code
Example G 50 B S 113 M H D R 2 C 1B
Product type Gearbox G
Product family 50
Version B
Gearbox type Sha-mounted helical gearbox S
Output torque
130 Nm 113
220 Nm 122
400 Nm 140
660 Nm 166
950 Nm 195
2100 Nm 221
3100 Nm 231
4500 Nm 245
8000 Nm 280
14000 Nm 314
19000 Nm 319
Type of construcon
Geared motor M
Gearbox N
Sha version
Solid sha with featherkey V
Hollow sha with keyway H
Hollow sha with shrink disc S
Housing type
Foot mounng + centering A
Foot mounng B
With centering C
Threaded pitch circle D
Flange version
Without ange R
Flange with through holes K
Number of stages
2-stage 2
3-stage 3
4-stage 4
Motor mounng
Integrated motor C
IEC adapter with jaw coupling
N
T
IEC adapter with plug-in hollow
sha
H
NEMA adapter with jaw coupling A
NEMA adapter with plug-in
hollow sha
B
Servo motor adapter with plug-in
hollow sha
S
Servo motor adapter with jaw
coupling
E
D
G
Drive size 1A
...
□H
08
...
82
Product codes
144
