Posion of the connecons
Standard connecon One Cable Technology (OCT)
1
2
3
Posion Meaning Posion Meaning
1 ICN-M23 connector, 6-pole
ICN-M40 connector, 8-pole
•
Power connecon
•
Brake connecon
•
PE connecon
3 For One Cable Technology (OCT)
ICN-M23 connector, hybrid
ICN-M40 connector, hybrid
•
Power connecon
•
Brake connecon
•
PE connecon
•
Connecon of digital absolute value encoder
•
Connecon of temperature monitoring
2 ICN-M23 connector
•
Feedback connecon
•
Connecon of temperature monitoring
Motor/ICN connector assignment
Standard connecon: Power and brake
One Cable Technology (OCT): Power connecon, brake, feedback and temperature monitoring
Motor Connector Motor Connector Motor Connector
m850-S120/S3960 ICN-M23 m850-S140/S3240 ICN-M23 m850-S190/S3000 ICN-M23
m850-S120/M3960 ICN-M23 m850-S140/M3240 ICN-M23 m850-S190/M3000 ICN-M40
m850-S120/L3960 ICN-M23 m850-S140/L3240 ICN-M40 m850-S190/L2520 ICN-M40
Product extensions
Motor connecon
Connecon via ICN connector
130
