Lenze g500-S660 User Manual

Inverter mains connecon 400 V, Self-venlated motors
2 kW
Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
17.0 1082 2.7 52.0 876 8.063 3.661 S130 120S40 2 12
21.0 865 5.6 64.0 788 9.407 4.579 S400 120S40 2 17
23.0 789 2.4 71.0 697 7.387 5.021 S130 120S40 2 12
25.0 752 5.3 74.0 679 8.044 5.267 S220 120S40 2 14
27.0 676 4.8 82.0 650 8.361 5.860 S400 120S40 2 17
30.0 618 4.5 90.0 610 8.076 6.411 S400 120S40 2 17
30.0 616 2.1 87.0 616 7.073 6.425 S130 120S40 2 12
32.0 585 5.1 95.0 447 8.141 6.767 S220 120S40 2 14
32.0 576 5.9 97.0 513 9.984 6.880 S660 120S40 2 23
33.0 563 2.0 92.0 563 6.988 7.029 S130 120S40 2 12
36.0 517 4.4 108 384 7.999 7.667 S220 120S40 2 14
36.0 514 5.9 108 461 11.580 7.702 S950 120S40 2 42
39.0 476 2.2 116 369 7.185 8.322 S130 120S40 2 12
43.0 427 3.7 131 360 7.536 9.280 S220 120S40 2 14
44.0 421 2.1 125 323 7.530 9.411 S130 120S40 2 12
48.0 387 5.6 144 353 7.822 10.240 S400 120S40 2 17
49.0 377 3.3 148 310 7.461 10.514 S220 120S40 2 14
52.0 352 5.9 158 314 8.906 11.262 S660 120S40 2 23
53.0 347 1.8 130 281 6.921 11.413 S130 120S40 2 12
54.0 342 5.4 163 309 7.698 11.569 S400 120S40 2 17
55.0 333 2.9 167 294 7.219 11.876 S220 120S40 2 14
57.0 321 5.6 173 293 8.622 12.320 S660 120S40 2 23
60.0 309 5.9 181 275 8.716 12.832 S660 120S40 2 23
60.0 307 1.6 130 235 7.104 12.907 S130 120S40 2 12
61.0 305 2.6 183 274 7.121 12.992 S220 120S40 2 14
61.0 302 4.7 184 291 7.393 13.105 S400 120S40 2 17
63.0 294 2.5 189 254 7.173 13.456 S220 120S40 2 14
65.0 282 5.6 197 257 8.463 14.037 S660 120S40 2 23
67.0 276 4.3 202 271 7.267 14.336 S400 120S40 2 17
68.0 271 1.4 130 229 6.788 14.606 S130 120S40 2 12
69.0 269 2.3 207 237 7.083 14.720 S220 120S40 2 14
69.0 268 4.2 208 252 7.317 14.806 S400 120S40 2 17
73.0 252 4.8 221 245 8.013 15.714 S660 120S40 2 23
74.0 248 1.3 130 211 6.750 15.979 S130 120S40 2 12
75.0 248 5.9 225 222 10.012 16.000 S950 120S40 2 42
75.0 245 3.8 228 235 7.204 16.197 S400 120S40 2 17
77.0 239 2.1 220 239 6.942 16.571 S220 120S40 2 14
83.0 221 4.8 252 215 7.915 17.905 S660 120S40 2 23
83.0 221 5.9 252 198 9.842 17.905 S950 120S40 2 42
84.0 219 1.3 130 187 6.844 18.069 S130 120S40 2 12
85.0 217 3.9 257 217 7.031 18.286 S400 120S40 2 17
87.0 211 2.1 220 211 6.918 18.776 S220 120S40 2 14
90.0 206 4.6 271 206 7.654 19.250 S660 120S40 2 23
95.0 195 1.9 220 195 6.836 20.300 S220 120S40 2 14
95.0 194 1.1 130 183 6.675 20.381 S130 120S40 2 12
96.0 192 3.4 291 192 6.992 20.659 S400 120S40 2 17
102 181 4.6 309 181 7.589 21.933 S660 120S40 2 23
104 177 3.2 315 177 6.896 22.400 S400 120S40 2 17
107 172 1.7 220 172 6.820 23.000 S220 120S40 2 14
107 172 1.0 130 155 6.732 23.048 S130 120S40 2 12
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
63
