Dimensions of the oil compensaon reservoir
For the following gearboxes in mounng posion M4 (C), which exceed the specied min.
input speed, an oil expansion reservoir is required depending on the specied gear rao:
g500-S2100 g500-S3100 g500-S4500
Gearbox rao Min. input speed Gearbox rao Min. input speed Gearbox rao Min. input speed
rpm rpm rpm
4.593 2000 4.951 2000 4.914 2000
6.029 2000 6.499 2000 6.450 2000
6.870 2000 7.406 2000 7.056 2000
8.272 2000 8.917 2000 8.944 2000
9.452 2000 10.932 2000 9.984 2000
10.504 2000 11.128 2000 11.740 2000
12.406 2000 12.584 2000 12.843 2000
13.787 2000 14.606 2000 13.105 2000
14.137 2000 16.517 2000 14.336 2000
15.711 2000 16.644 2000 16.381 2000
17.022 3000 18.822 2000 18.286 2000
18.917 3000 20.041 3000 20.067 2000
20.869 3000 22.663 3000 22.400 2000
23.193 3000 24.570 3000 26.437 3000
28.275 3000 27.785 3000 29.511 3000
31.422 3000 33.289 3000 32.489 3000
34.333 3000 37.644 3000 36.267 3000
38.156 3000 40.422 3000 42.044 3000
44.431 4000 45.711 3000 46.933 3000
49.378 4000 52.311 4000 51.027 4000
53.924 4000 59.156 4000 56.960 4000
59.927 4000 63.487 4000 64.500 4000
68.162 4000 71.793 4000 72.000 4000
75.750 4000
Informaon on project planning
Final conguraon
Venlaon
38
