Mechanical installation
Mounting
General information about the assembly of drive systems
5
29
Lenze • BA 12.0023 • 9.0
Condensation drain hole
Note!
Lenze delivers motors with condensation drain holes with sealed
condensation drain holes. The holes are sealed with a plastic plug or a
locking screw. This does not affect the type of protection and the motor is
protected against the ingress of foreign substances during transport and
operation. Further information, ( 57).
5.3.2 General information about the assembly of drive systems
Stop!
The lubricant fill quantity of the gearboxes is matched to the mounting
position. The mounting position indicated on the nameplate must be
observed to avoid damage to the gearbox.
• Take safety measures prior to any operation:
– Disconnect the machine from the mains, ensure standstill of the drive system
and avoid any machine movement.
– Check faultless state of the drive system. Never install and commission
damaged drive systems.
– Check drive function - machine function assignment. Check direction of
( 28)rotation.
• The mounting surfaces must be plane, torsionally rigid and free from vibrations.
• Align drive system on mounting surfaces exactly with the machine shaft to be
driven.
– Be sure to carry out mounting in a manner free from d istortion, in order to avoid
additional loads.
– Even out slight inaccuracies by the use of suitable flexible couplings.
• Support reaction torque by suitable measures.
• Be absolutely sure to secure fastenings of accessories and built-on accessories so
that they won’t come loose.
We recommend glueing screwed connections.
5.3.3 Assembly of transmission elements on solid shafts
Draw the transmission elements onto the output shaft only by using the centering
thread.
Stop!
Shocks and blows to the shafts damage the roller bearings.
