Operating instructions i550 cabinet frequency inverter | 4
© 11/2021 · EN · www.Lenze.com
Identication of the products
General information









1
Product generation
A
Generation 1
B
Generation 2
2
Rated power
[kW]
125 0.25
137 0.37
155 0.55
175 0.75
211 1.1
215 1.5
222 2.2
230 3
240 4
255 5.5
275 7.5
311 11
315 15
318 18.5
322 22
330 30
337 37
345 45
355 55
375 75
390 90
411 110
3
Mains voltage and connection type
A
1/N/PE AC 120 V
B
1/N/PE AC 230/240 V
C
3/PE AC 230/240 V
D
1/N/PE AC 230/240 V
3/PE AC 230/240 V
F
3/PE AC 400 V
3/PE AC 480 V
4
Integrated functional safety
0
Without safety function
A
Basic Safety - STO
5
Interference suppression
0
Without
1
Integrated RFI lter
6
Application area
0
Default parameter setting: Region EU (50-
Hz networks)
1
Default parameter setting: Region US (60-
Hz networks)
7
Design types
000S
Standard I/O without network
001S
Application I/O without network
002S
Standard I/O with CANopen
003S
Standard I/O with Modbus RTU
004S
Standard I/O with PROFIBUS
012S
Standard I/O with POWERLINK
00KS
Standard I/O with EtherCAT
00LS
Standard I/O with PROFINET
00MS
Standard I/O with EtherNet/IP
00WS
Standard I/O with Modbus TCP
016S
Standard I/O with IO-Link
5 5 A 137 FI A 0 0 000S
2 3 4 5 6 71
E
1 V
Identication
Information
Overview Conventions

Lenze i550 Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Safety	STO (Safe Torque Off)
Voltage Range	380 V to 480 V
Control Type	Vector control, V/f control
Communication Interfaces	CANopen, EtherCAT, PROFINET, Ethernet/IP
Mains Voltage	3-phase 380 V to 480 V
Input Voltage	3-phase 380 V to 480 V
Output Voltage	0 to Mains Voltage
Frequency Range	0 Hz to 300 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10°C to 50°C
