Operating instructions i550 cabinet frequency inverter | 46
© 11/2021 · EN · www.Lenze.com
LED status
Meaning of the status LEDs for the inverter:
LED “RDY” (blue)) LED “ERR” (red)) State/meaning
o o No supply voltage
Mains voltage is switched on, inverter initialized
blinking
o Inverter disabled, ready for operation
blinking fast
Safe torque o (STO) active,
warning active
blinking
o Inverter disabled
blinking fast
Inverter disabled, warning active.
Inverter disabled, error active.
on briey every 1.5s
Inverter disabled, no DC bus voltage.
o Inverter enabled
o
The motor rotates according to the specied
setpoint or quick stop active.
blinking fast
Inverter enabled, warning active. The motor
rotates according to the specied setpoint or
quick stop active.
blinking
Inverter enabled, quick stop active as response
to a fault.
Troubleshooting
Error codes
LED statusError message
