Operating instructions i550 cabinet frequency inverter | 9
© 11/2021 · EN · www.Lenze.com
Mechanical installation
Important notes
NOTE
UL marking
Modular construction - A complete drive consists of a power unit series no. I5D in combination
with a control unit series no. I5C only.
Marquage UL
Conception modulaire – Le système d’entraînement complet comprend un module
d’alimentation de série I5D, impérativement associé à une unité de commande de série I5C.
PreparationImportant notes
Dimensions and assembly
