Lenze II EPZ-10202 User Manual

Extension Board II EPZ-10202
for Drive PLC
EDK10202EZ3 4.1
l
Lenze Drive Systems GmbH, Postfach 10 13 52, D-31763 Hameln
 (+49) 5154 82-0, Fax Service: (+49) 5154 82-1112
These Instructions
y contain the most important technical data, describe the installation, handling and
commissioning of the extension board II.
y are only valid
- for the extension board II with the type designation EPZ-10202
- together with the Mounting Instructions for the Drive PLC.
Description
Theextension board II extends the DrivePLC by 14 digital inputs and eight digital outputs.
Scope of application
Applicable together with the Drive PLC type EPL-10200-EI
Accessories
Items supplied
- two plug connectors, 2 x 13 pole each (already assembled at EPL-10202-EI)
- two terminal strips, six-pole each for digital inputs (I9 ... I14 und I15 ... I20)
- one 6-pole terminal strip for digital inputs (05 ... 010)
- one 6-pol terminal strip for output voltage (+024, ⊥24),
digital inputs (I21, I22), digital outputs (011, 012)
General data and application conditions
Conformity CE Low-Voltage Directive (73/23/EEC)
Approvals UL 508C Underwriter Labora tories (File-No. E132659)
Power Conversion Equipment
DC supply voltage
Voltage external +18 VDC -0 % ... +30 VDC +0 %
D
C
s
u
p
p
l
y
v
o
l
t
a
g
e
Current max. 8 A
(at max. load of all outputs)
Climatic conditions Class 3K3 to EN 50178
(without condensation, average relative humidity 85 %)
Temperature range
Transport -25°C...+70°C
T
e
m
p
e
r
a
t
u
r
e
r
a
n
g
e
storage -25°C...+60°C
Operation 0 °C ... +40 °C without power derating
+40 °C ... +55 °C with power derating
Power derating of output currents for t
a
>+40°C:2.5%/K
Vibration resistance Resistant to acceleration up to 0.7 g
Permissible mounting
positions
in the Drive PLC on a plug-in-station for extension board
Insulation voltage to PE 50 V AC
Enclosure IP 20
Digital inputs
Level LOW (0 V ... +4 V)
HIGH (+13 V ... +30 V)
Input current max.8mAat24V
Digital outputs
Level LOW (0 V ... +4 V)
HIGH (+13 V ... +30 V)
Load capacity max. 1 A per output
Dimensions
Height 145 mm (incl. terminal strips)
D
i
m
e
n
s
i
o
n
s
Width 72 mm
Depth 35 mm
EDK10202EZ3
00465733
05/03
