Terminal assignment
EDK10202EZ3 4.1
l
-3-
Terminals - overview
X1
X2
X3
X4
terminals Assignment
X1 Digital outputs (X1/O5 ... X1/010)
X2
Digital inputs (X2/I21, X2/I22)
X
2
Digital outputs (X2/O11, X2/O12)
DC supply voltage (X2/ ⊥24, X2/+O24)
X3 Digital inputs (X3/I15 ... X3/I20)
X4 Digital inputs (X4/I9 ... X4/I14)
