4.2 Rated data of the devices for HV on−board supply system 800 V
4.2.1 Product finder
How to find the data for the desired MOBILE device:
Device Type DC/AC inverter DC/DC converter
X12 X13 X21
MOBILE DCU
EMDAG2603603U 60 kW 60 kW ˘
EMDAG2303303U 30 kW 30 kW ˘
EMDAG2303153U 30 kW 15 kW ˘
EMDAG2153752U 15 kW 7.5 kW ˘
MOBILE PSU
EMDAG3562000C ˘ ˘ 5.6 kW, 24 V
EMDAG3282000T ˘ ˘ 2.8 kW, 12 V
MOBILE DCU PSU
EMDAG4562603C ˘ 60 kW 5.6 kW, 24 V
EMDAG4282603C ˘ 60 kW 2.8 kW, 24 V
EMDAG4562303C ˘ 30 kW 5.6 kW, 24 V
EMDAG4282303T ˘ 30 kW 2.8 kW, 12 V
EMDAG4562153C ˘ 15 kW 5.6 kW, 24 V
EMDAG4282153T ˘ 15 kW 2.8 kW, 12 V
X3
MOBILE DCU S
EMDAG5223000U 22 kW ˘ ˘
EMDAG5153000U 15 kW ˘ ˘
EMDAG5113000U 11 kW ˘ ˘
EMDAG5752000U 7.5 kW ˘ ˘
How to find the data: ^ 27 ^ 30
