Lenze MOBILE DCU User Manual

Accessories (overview)
Individual parts for the electrical installation
MOBILE DCU S
8
Ò
73
EDSMDAG EN 2.0
HV on−board supply system at X2
Name
Type Manufacturer
HVA280 cable 2 × 4mm
2
A coded
500 mm
1−2208103−0
TE Connectivity
1000 mm 1−2208103−1
2000 mm 1−2208103−2
3000 mm 1−2208103−3
4000 mm 1−2208103−4
5000 mm 1−2208103−5
6000 mm 1−2208103−6
HVA280−2PHM
Individual parts
Plug Sub−Assy Code A 1× per X2 4−2103015−1
Collet Size 1 1× per X2 2103155−1
Seal Retainer Size 1 1× per X2 2103013−1
Seal Cable Size 1 1× per X2 2103154−1
Outer Ferrule Size C 1× per X2 1587724−3
Plug Shield Size 1 2× per X2 1−2103157−1
Spacer 1× per X2 2103153−1
Inner Ferrule Size C 1× per X2 1587723−3
Inner Housing 1× per X2 1587985−1
AMP MCP 2.8K Contact 4mm
2
silverplated
2× per X2 1−968853−3
Power Cable 2 × 4mm
2
2177114−1
Motor at X3
Name
Type Manufacturer
HVA280 cable 3 × 2.5mm
2
B−coded
500 mm
2−2177626−0
TE Connectivity
4000 mm 2−2177626−4
HVA280−3PXM
Individual parts
Plug Sub−Assy Code B 1× per X2 4−2103015−2
Collet Size 2 1× per X2 2103155−2
Seal Retainer Size 2 1× per X2 2103013−3
Seal Cable Size 2 1× per X2 2103154−2
Outer Ferrule Size B 1× per X2 1587724−2
Plug Shield Size 2 2× per X2 1−2103157−2
Spacer 1× per X2 2103153−1
Inner Ferrule Size B 1× per X2 1587723−2
Inner Housing 1× per X2 2103306−1
AMP MCP 2.8K Contact
1.0...2.5mm
2
silverplated
3× per X2 1241390−3
Power Cable 3 × 2.5mm
2
2177877−1
