Lexicon RV-5 User Manual

Basic Operation Lexicon
2-5
REAR-PANEL OVERVIEW
The RV-5 rear panel is shown below. The numbers in the rear-panel illustrations correspond with the numbered items in the text.
1. Microphone Input Connectors
2. Analog Audio Input Connectors
3. Main Zone Audio Output Connectors
4. Digital Input Connectors
5. USB Connector Port
6. Trigger Output Connectors
7. RS-232 Connector
8. Video Input Connectors
9. Main Zone Video Ouput Connectors
10. Component Video Input Connectors
11. HDMI Input Connectors
12. Power Switch
13. AC Input Connector
14. Amplifier Outputs
15. IR In Connector
16. Dock Connector
17. Zone 2 Digital Audio Output Connectors
18. Preamplifier Outputs
19. Tuner Antenna Connectors
2
5
4
1
3
6 7
8
9
10
13
19
14
16
18
11
12
15
17
