Lexicon RV-5 User Manual

Introduction Lexicon
ii
DOCUMENTATION CONVENTIONS
This document contains general safety, installation and operation instructions for the RV-8 Receiver. It is important to read this user guide before
attempting to use the product. Pay particular attention to safety instructions.
The following symbols are used in the document:
Appears on the component to indicate the pres-
ence of uninsulated, dangerous voltage inside
the enclosu
re – voltage that may be sufficient to
constitute a risk of shock.
Appears on the component to indicate impor-
tant operating and maintenance instructions in
the accompanying literature.
Calls attention to a procedure, practice, condi-
tion or the like that, if not correctly performed
or adhered to, could result in injury or death.
Calls attention to a procedure, practice, condi-
tion or the like that, if not correctly performed
or adhered to, could result in damage or
destruction to part or all of the product.
Calls attention to information that is essential to
highlight.
Represents a menu path. The menu items in gray boxes must be
selected with the remote control Menu  arrow to access the
menu or menu item in the black box. For example, the SETUP,
INPUTS, and DVD1 menu items must be selected to open the
DVD1 INPUT SETUP menu.
The DVD1 INPUT SETUP menu is used here as an example and will
continue to be used as an example throughout this document.
Whenever it appears, any other INPUT SETUP menu may be substi-
tuted. Likewise, whenever the DVD1 input appears as a step in a
menu path, any other input may be substituted.
WARNING
CAUTION!
Note:
DVD1
INPUTSSETUP
NAME
EDIT INPUT NAME
This document uses the term DTS(-ES) to indicate that DTS-ES encoding may or may not be present in the input source.
