• For non‑touch‑screen printer models, press to
confirm.
Scanner jam, remove all originals from the scanner [2yy.xx]
Remove the jammed paper from the scanner.
Scanner jam, remove jammed originals from the scanner [2yy.xx]
Remove the jammed paper from the scanner.
SMTP server not set up. Contact system administrator.
From the printer control panel, press to clear the message.
Note: If the message appears again, then contact your system support person.
Standard network software error [54]
Try one or more of the following:
• From the printer control panel, select Continue to continue printing. For non‑touch‑screen printer
models, press
to confirm.
• Turn o the printer and then turn it back on.
• Update the network firmware in the printer or print server. For more information, visit the Lexmark
support Web site at
http://support.lexmark.com.
Standard USB port disabled [56]
From the printer control panel, select Continue to clear the message. For non‑touch‑screen printer models,
press
to confirm.
Notes:
• The printer discards any data received through the USB port.
• Make sure the USB Buer menu is not set to Disabled.
Supply needed to complete job
Try one or more of the following:
• From the printer control panel, touch Prompt for supplies to view all error messages that indicate what
supplies are needed to continue processing the current job. For non‑touch‑screen printer models, press
to clear the message and continue printing.
1 Order the missing supply immediately.
2 Install the supply. For more information, see the instruction sheet that came with the supply.
• Cancel the print job, then install the missing supply, and then resend the print job.
Troubleshooting 179

Lexmark CX317dn Specifications

General

Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, GOST-R, SII, TER
Sustainability certificates	Blue Angel, ENERGY STAR
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	11.5 s
Time to first page (color, normal)	12.5 s
Print speed (black, normal quality, A4/US Letter)	23 ppm
Duplex print speed (black, normal quality, A4/US Letter)	12 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	23 cpm
Scan to	E-mail, FTP, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Scan speed (color)	30 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution (black)	1200 x 600 ppi
Optical scanning resolution (color)	600 x 600 ppi
Faxing	No
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	60000 pages per month
Recommended duty cycle	500 - 5000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Universal
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Internal memory	512 MB
Processor cores	2
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound power level (standby)	16 dB
Sound pressure level (copying)	48 dB
Sound pressure level (printing)	7 dB
Sound pressure level (scanning)	49 dB
Sound pressure level (duplex printing)	50 dB
Display	LCD
Product color	Gray
Display diagonal	2.4 \
Market positioning	Business
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Power consumption (max)	540 W
Power consumption (off)	0.5 W
Power consumption (ready)	30 W
Power consumption (sleep)	2.5 W
Power consumption (scanning)	40 W
Power consumption (average operating)	500 W
Other operating systems supported	HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 9 SPARC
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Package depth	594 mm
Package height	567 mm
Package weight	31430 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Paper input type	Paper tray
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	901 sheets
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	50 sheets
Included cartridge capacity (CMY)	750 pages
Included cartridge capacity (black)	1400 pages

Weight and Dimensions

Depth	558 mm
Width	444 mm
Height	470 mm
Weight	27390 g
