Lexmark MX310dn User Manual

Scanning to a computer
Automatic document feeder (ADF) Scanner glass
Use the ADF for multiple‑page documents. Use the scanner glass for single pages, small items (such as postcards or
photos), transparencies, photo paper, or thin media (such as magazine
clippings).
The scanner lets you scan documents directly to a computer. The computer does not have to be directly connected to
the printer for you to receive Scan to PC images. You can scan the document back to the computer over the network
by creating a scan profile on the computer and then downloading the profile to the printer.
Scanning to a computer
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears as four
sets of numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Scan Profile > Create Scan Profile.
3 Select your scan settings, and then click Next.
4 Select a location on your computer where you want to save the scanned output file.
5 Type a scan name.
The scan name is the name that appears in the Scan Profile list on the display.
6 Click Submit.
7 Review the instructions on the Scan Profile screen.
A shortcut number is automatically assigned when you click Submit. You can use this shortcut number when you
are ready to scan your documents.
a Load an original document faceup, short edge first into the ADF tray or facedown on the scanner glass.
Scanning 96

Lexmark MX310dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Finishing option	No
All-in-one functions	Copy, Fax, Print, Scan
Supported media weight(s)	60 - 90 g/m²
Color all-in-one functions	Scan
Package dimensions (W x D x H)	19.09 x 21.65 x 22.48 \
Supported media weight (imperial)	24 lbs
Country of origin	China
Maximum duty cycle	50000 pages per month
Recommended duty cycle	250 - 6000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS
Copier resize	25 - 400 %
Copy speed (black, normal quality, A4)	33 cpm
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Duplex scan speed (black)	43 ppm
Duplex scan speed (color)	20 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	-
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Display diagonal	2.4 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	TCP/IP, AppleTalk, TCP, UDP
Supported network protocols (IPv6)	TCP/IP
Internal memory	256 MB
Processor frequency	800 MHz
Sound pressure level (copying)	54 dB
Sound pressure level (printing)	53 dB
Sound pressure level (scanning)	55 dB
Sound pressure level (duplex printing)	52 dB
Power consumption (average operating)	- W
Package depth	550 mm
Package width	485 mm
Package height	571 mm
Package weight	22500 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	ENERGY STAR
Certification	Blue Angel (RAL-UZ-122), CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 B, BSMI B, CNS 13438, VCCI B, US FDA, FCC B, UL 60950-1, IEC 320-1, EN/IEC 60320-1, CE B, CB IEC 60950-1, EN 62311, EN 60950-1, EN/IEC 61000-3, EN 55022 B, EN 55024, EN/IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, SMA C-tick B, CCC B, CISPIR 22 B, EK Mark, N Mark, ECMA-370, TED

Weight and Dimensions

Depth	472 mm
Width	399 mm
Height	468 mm
Weight	20000 g
