ASSEMBLING AND PREPARING / MAKING CONNECTIONS
Tidying cables
Image shown may differ from your TV.
(Only LB55**)
1 Gather and bind the cables with the Cable
Holder and the Cable Management.
2 Attach the cable management to TV.
Cable Holder
Cable
Management
(Only LB51**)
Gather and bind the cables with the Cable
Holder.
Cable Holder
CAUTION
y
Do not move the TV by holding the cable
holders, as the cable holders may break,
and injuries and damage to the TV may
occur.
MAKING CONNECTIONS
This section on MAKING CONNECTIONS
mainly uses diagrams for the LB55** models.
Connect various external devices to the TV
and switch input modes to select an external
device. For more information of external device’s
connection, refer to the manual provided with
each device.
Available external devices are: HD receivers,
DVD players, VCRs, audio systems, USB
storage devices, gaming devices, and other
external devices.
NOTE
y
The external device connection may differ
from the model.
y
Connect external devices to the TV
regardless of the order of the TV port.
y
If you record a TV programme on a
DVD recorder or VCR, make sure to
connect the TV signal input cable to the
TV through a DVD recorder or VCR. For
more information of recording, refer to
the manual provided with the connected
device.
y
Refer to the external equipment’s manual
for operating instructions.
y
If you connect a gaming device to the TV,
use the cable supplied with the gaming
device.
