LG 32LD330C User Manual

EXTERNAL EQUIPMENT SETUP
43
HDMI Connection
Connect the digital set-top box to the
HHDDMMII//DDVVII IINN
*,
HHDDMMII//DDVVII IINN 11
* or
HHDDMMII//DDVVII IINN 11((DDVVII))
*,
HHDDMMII
22
* or
HHDDMMII IINN 22
*/
33
* jack on the TV.
No separate audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
HDMI
/DVI IN
HDMI
/DVI IN
HDMI HDMI
(CONTROL)
RGB IN (PC)
COMPONENT IN
AUDIOAUDIO
VIDEOVIDEO
11
22
HDMI OUTPUT
1
GG
Check HDMI cable over version 1.3.
If the HDMI cables don’t support HDMI version
1.3, it can cause flickers or no screen display. In
this case use the latest cables that support
HDMI version 1.3.
GG
HDMI mode supports PCM audio format only.
GG
If the Audio setting is set to Dolby/DTS/Bitstream
in some DVDP/STB, make sure to change the set-
ting to PCM.
NOTE
!
*
HHDDMMII//DDVVII IINN
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII//DDVVII IINN 11,, 22::
For 26/32LD330, 32LD340, 26/32LD331C
*
HHDDMMII//DDVVII IINN 11
,
HHDDMMII ((IINN)) 22
: For 26/32/37/42LH20R, 32/37/42/47LH30FR, 19LU50R, 22/26LU50FR,
32/42LF20FR, 32/42LD410
*
HHDDMMII IINN 33
: For 32/37/42/47LH30FR, 26LU50FR, 32/42LD410, 32LD420
*
HHDDMMII//DDVVII IINN 11((DDVVII))
,
HHDDMMII IINN 22
/
33
: For 42/47/55LH50YR, 32/42/47LH70YR, 42/47LH90QR, 32/42/47/55SL80YR,
42/47SL90QR, 32/42LD420
2. How to use
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select the
HHDDMMII
*or
HHDDMMII11
*/
22
*/
33
* input source on the
TV using the
IINNPPUUTT
button on the remote control.
*
HHDDMMII
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII11
/
22
: Except 19/22LH20R, 22LD330
*
HHDDMMII33
: For 32/37/42/47LH30FR, 26LU50FR,
42/47/55LH50YR, 32/42/47LH70YR,
42/47LH90QR, 32/42/47/55SL80YR,
42/47SL90QR, 32/42LD410, 32/42LD420
Resolution
720x480
720x576
1280x720
1920x1080i
1920x1080p
HDMI-DTV mode
Horizontal Vertical
Frequency(kHz) Frequency(Hz)
31 . 47 59 . 9 4
31.50 60.00
31.25 50.00
44.96 59.94
45.00 60.00
37.50 50.00
33.72 59 .94
33.75 60.00
28.125 50.00
67.432 59.94
67.50 60.00
56.25 50.00
27.00 24.00
33.75 30.00
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 43
