EXTERNAL EQUIPMENT SETUP
44
EXTERNAL EQUIPMENT SETUP
DVI to HDMI Connection
L R
DVI OUTPUT
AUDIO
L(MONO)
VIDEO
HDMI
/DVI IN
HDMI
/DVI IN
HDMI HDMI
RS-232C IN
(CONTROL)
RGB IN (PC)
USB IN
SERVICE ONLY
A
AV
COMPONENT IN
AUDIOAUDIO
VIDEOVIDEO
VARIABLE AUD
11
22
AUDIO IN
(RGB/DVI)
AUDIO IN
(RGB/DVI)
1
2
Connect the DVI output of the digital set-top box to the
HHDDMMII//DDVVII IINN
*,
HHDDMMII//DDVVII IINN 11
*, or
HHDDMMII//DDVVII
IINN 11((DDVVII))
* jack on the TV.
Connect the digital set-top box audio output to the
AAUUDDIIOO IINN ((RRGGBB//DDVVII))
jack on the TV.
1. How to connect
2. How to use
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select the
HHDDMMII
*, or
HHDDMMII11
* input source on the TV
using the
IINNPPUUTT
button on the remote control.
*
HHDDMMII//DDVVII IINN
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII//DDVVII IINN 11
: For 26/32/37/42LH20R, 32/42LF20FR,
32/37/42/47LH30FR, 19LU50R, 22/26LU50FR,
26/32LD330, 32/42LD410, 32/42LD420, 32LD340,
26/32LD331C
*
HHDDMMII//DDVVII IINN 11((DDVVII))
: For 42/47/55LH50YR, 32/42/47LH70YR, 42/47LH90QR,
32/42/47/55SL80YR, 42/47SL90QR
GG
A DVI to HDMI cable or adapter is required for this
connection. DVI doesn't support audio, so a separate
audio connection is necessary.
GG
HDMI mode supports PCM audio format only.
GG
If the Audio setting is set to Dolby/DTS/Bitstream in
some DVDP/STB, make sure to change the setting to
PCM.
NOTE
!
*
HHDDMMII
: For 19/22LH20R, 22LU40R, 22LD330
*
HHDDMMII11
: Except 19/22LH20R, 22LU40R, 22LD330
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 44
