3
ENGLISH
PREPARATION
STAND INSTALLATION
■
Image shown may differ from your TV
When assembling the desk type stand, check whether the
bolt is fully tightened. (If not tightened fully, the product
can tilt forward after the product installation.) If you tight-
en the bolt with excessive force, the bolt can deviate from
abrasion of the tightening part of the bolt.
1
3
4
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
2
Assemble the parts of the
SSttaanndd BBooddyy
with
the
CCoovveerr BBaassee
of the TV.
Assemble the TV as shown.
Fix the 4 bolts securely using the holes in the
back of the TV.
Stand Body
Cover Base
32/37/42LG70
**
only
■
Image shown may differ from your TV.
When installing the wall-mounted unit, use the pro-
tection cover for desk-type stand installation.
NOT USING THE DESK-TYPE
STAND
Insert the
PPRROOTTEECCTTIIOONN CCOOVVEERR
into the
TV until clicking sound.
ATTACHING THE TV TO A
DESK (32/37LG70
**
only )
The TV must be attached to desk so it cannot be
pulled in a forward/backward direction, potentially
causing injury or damaging the product. Use only an
attached screw.
1-Screw
(provided as parts of the product)
Desk
Stand
WARNING
G
To prevent TV from falling over, the TV should
be securely attached to the floor/wall per
installation instructions. Tipping, shaking, or
rocking the machine may cause injury.
To Next Page
