LG 32LK4 Series User Manual

1
EXTERNAL EQUIPMENT SETUP
IN
RS-232C IN
(CONTROL&SERVICE)
ANTENNA
IN
COMPONENT IN
AV IN 1
AUDIO
VIDEO
L(MONO)
R
AUDIO
IN1
VIDEO
1
2
2
VARIABLE AUDIO OUT
AV IN2
IN 3
AUDIO IN
(RGB/DVI)
RGB IN (PC)
/DVI IN
1
ANTENNA CONNECTION
■ For optimum picture quality, adjust antenna direction.
■ An antenna cable and converter are not supplied.
■ To prevent damage do not connect to the mains outlet until all connections are made between the devices.
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
(VHF, UHF)
Wall
Antenna
Socket
RF Coaxial Wire (75
Ω)
Antenna
UHF
Signal
Amplifier
VHF
■ In poor signal areas, to achieve better picture quality it may be necessary to install a signal amplifier
to the antenna as shown above.
■ If signal needs to be split for two TVs, use an antenna signal splitter for connection.
EXTERNAL EQUIPMENT SETUP
IN
RS-232C IN
(CONTROL&SERVICE)
ANTENNA
IN
COMPONENT IN
AV IN 1
AUDIO
VIDEO
L(MONO)
R
AUDIO
IN1
VIDEO
1
2
2
VARIABLE AUDIO OUT
AV IN2
IN 3
AUDIO IN
(RGB/DVI)
RGB IN (PC)
/DVI IN
1
