LG 32UD60 User Manual

12
ENG
ENGLISH
Adjusting the angle
1
Place the monitor in an upright position, mounted
on the stand base.
2
Adjust the angle of the screen. The angle of the
screen can be adjusted forwards or backwards for a
comfortable viewing experience.
Front SideRear Side
y
To avoid injury to the fingers when adjusting the
screen, do not hold the lower part of the moni-
tor's frame as illustrated below.
WARNING
y
Be careful not to touch or press the screen area
when adjusting the angle of the monitor.
Adjusting the stand height
1
Handle the monitor with both hands for safety.
2
The height can be adjusted up to 4.72 inches.
4.72 inches
y
Do not put your fingers or hand
between the screen and the
base (chassis) when adjusting
the screen's height.
WARNING
Monitor head
y
The left or right side of the monitor head can be
slightly rotated up or down (up to 3°). Adjust the
horizontal level of the monitor head.
NOTE

LG 32UD60 Specifications

General

3D	No
DDC/CI	Yes
Panel type	VA
Color depth	10 bit
Color gamut	95 %
Pixel pitch	0.181 x 0.181 mm
Aspect ratio	4:3, 16:9
Screen shape	Flat
Display diagonal	32 \
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
RMS rated power	10 W
Number of speakers	2
Product color	Black
Market positioning	Gaming
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	50 W
Power consumption (PowerSave)	39 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth (with stand)	236.2 mm
Height (with stand)	457.2 mm
Weight (with stand)	7121 g
Depth (without stand)	50.8 mm
Width (without stand)	728.9 mm
Height (without stand)	424.1 mm
Weight (without stand)	5307 g
